Garden Terrace @ Tengah

HDB BTO Sales Launch Announcement

HDB BTO sales launch brochure cover for Garden Terrace @ Tengah, announced for November 2020. The upper half features a computer-generated rendering of the residential development, showcasing multiple HDB blocks with a beige and white facade, surrounded by lush green landscaping, mature trees, and communal facilities. A children's playground with a large red ladybug structure is visible within the green spaces. The lower half displays a lifestyle photograph of a smiling multi-ethnic couple, a man and a woman, holding a blue baby romper. They are positioned in a room with a light blue wall and a white baby crib, suggesting a family-oriented theme for the development.

Residential Development Overview: Block Heights and Unit Types

Artist's impression of a residential development located in Tengah town, within the Garden District. The development comprises 5 residential blocks, ranging from 7 to 16 storeys in height. A total of 789 units are available, including 2-room Flexi, 3-room, 4-room, and 5-room flat types. The project is bounded by Tengah Garden Avenue, Plantation Crescent, and Tengah Boulevard. Design inspiration comes from garden elements, featuring surrounding courtyards and roof gardens at varying heights. Upcoming nearby amenities include a Neighbourhood Centre, a Community Club, and Jurong Region Line MRT stations. The area will feature an extensive network of walking and cycling paths, with bus services connecting to the city and nearby towns.

HDB BTO Development Features and Amenities Overview

Overview of features and amenities for an HDB BTO development, likely 'Garden Terrace @ Tengah' within the 'Garden District'. Key Features: - The Garden Farmway: Promotes community gardening, hobby farming, and farm-to-table dining, fostering a new lifestyle and 'kampung spirit'. - Garden Terrace @ Tengah: Offers lushly landscaped courtyard gardens, activity nodes, children's playgrounds, and fitness stations. Includes roof gardens at residential blocks and above the Multi-Storey Car Park, plus a childcare centre. About Garden District: - Framed by Tengah Pond and Central Park. - Complemented by a garden-themed farmway for healthy and active living. - Thematic playgrounds inspired by nature motifs (flowers, garden creatures) to encourage imaginative play. - Green markers and botanical arbours at key entry points provide shade and visual respite. - Amenities available include eateries, schools, and retail shops to meet daily needs of residents.

Green Town Concept: Overview & Artist Impressions

Overview of a new HDB town's green and nature-centric development concept. The town is designed as a 'Green Haven' utilizing HDB's Biophilic Town Framework to create nature-centric neighborhoods focused on environmental health and well-being. A town-wide Active, Beautiful, Clean Waters (ABC Waters) design strategy will incorporate outdoor spaces and landscape features for stormwater management and to connect residents with nature. Key features include: - A 'Garden District' with residential blocks integrated into lush green recreational areas (artist's impression shown). - An approximately 100-metre wide and 5km long 'Forest Corridor' intended to connect to the Western Water Catchment Area and Central Catchment Nature Reserve, forming a rich forest habitat. - 'Tengah Town Centre - The Market Place', depicted as a central urban hub with green spaces and elevated rail transit (artist's impression shown). This page does not contain specific block numbers, unit types, or floor plans.

Artist's Impression: Car-lite Town Centre & Smart Town Features

This page provides an overview of a new HDB town's features and an artist's impression of its town centre. Town Concept & Green Spaces: The town integrates a 15-20 metre wide 'Forest Fringe' from the 'Forest Corridor,' offering a tranquil environment with flora and fauna. It includes extensive park spaces like 'Central Park' and 'Community Farmways' to connect amenities. Transportation & Connectivity: The town will feature Singapore's first car-free town centre, promoting green commuting with dedicated walking and cycling paths. Public transport will be served by the Jurong Region Line and bus services. Smart Town Features: Planned as a 'Smart Town' from the outset, it will integrate smart technologies and pilot autonomous vehicles for first-mile-last-mile connectivity to transport nodes and amenities. Commercial Facilities: Vibrant commercial facilities are planned within the town centre and districts, complementing existing shopping and dining options in nearby Bukit Batok. An artist's impression of the 'Car-lite Town Centre' illustrates multi-level retail, green spaces, and integrated public transport.

Important Notes on HDB Planning and Amenities

Important notes regarding HDB precinct planning and the indicative nature of information provided in the brochure. HDB precincts are designed to meet evolving community needs, incorporating spaces for future amenities and facilities. These include: - Childcare centres - Elderly-related facilities - Education centres - Residents' committee centres - Day activity centres - Commercial facilities (e.g., shops, eating houses) - Mechanical and electrical rooms These facilities may be located in void decks, common property, car parks, or standalone community buildings, depending on prevailing needs. Information presented in the brochure concerning surrounding land use and proposed facilities is indicative only. It is based on the current planning intent of relevant government agencies and is subject to review from time to time. This content is found on page 6 of the brochure.

Tengah Planning Area: Master Plan and Amenities Map

Master plan for the Tengah planning area, showing proposed and existing developments, and connectivity to surrounding towns like Jurong, Choa Chu Kang, and Bukit Batok. Key transport infrastructure includes the Pan Island Expressway (PIE), Kranji Expressway (KJE), and various MRT/LRT lines. Jurong Region Line (JRL) stations shown are Tengah, Hong Kah, Corporation, Jurong West, Plantation, Tengah Park, and Bukit Batok West (all under construction). Choa Chu Kang West MRT (JRL) and Keat Hong LRT stations are also indicated. Proposed amenities within Tengah include numerous parks (e.g., Forest Corridor, Forest Fringe), civic and community institutions, health and medical care facilities, places of worship, and schools (e.g., Dunearn Secondary School, St Anthony's Primary School). Specific proposed projects like 'Garden Terrace @ Tengah' are marked. Existing landmarks include Tengah Airbase, Keat Hong Camp, and Army Logistic Base. The map indicates future roads, common greens, and electrical substations. Notes clarify that all proposed developments are subject to change and are indicative only. Definitions for various facility types are provided, and the map scale extends up to 600 meters.

HDB BTO Property Features, Flat Specifications, and Optional Schemes

General property features, flat specifications, and optional schemes are detailed for HDB BTO units. Flat types offered include 2-room Flexi (available on 99-year or short-lease), 3-room, 4-room, and 5-room flats. All units are built using Prefabricated Prefinished Volumetric Construction (PPVC) and come with full floor finishes, internal doors, and sanitary fittings. 2-room Flexi flats feature vinyl strip flooring in living/dining/bedroom, floor tiles in household shelter/bathroom/kitchen, wall tiles in bathroom/kitchen, a sliding partition/door for the bedroom, a folding bathroom door, sanitary fittings, and grab bars (for short-lease). 3-, 4-, and 5-room flats include vinyl strip flooring in bedrooms, floor tiles in living/dining/kitchen/service yard/household shelter/bathrooms, wall tiles in kitchen/bathrooms, internal doors for bedrooms/bathrooms, and sanitary fittings. Eco-friendly features comprise separate recyclable waste chutes, regenerative lifts, bicycle stands, car-sharing schemes, sustainable products, and ABC Waters design. Smart solutions include smart-enabled homes (with provisions for systems), smart lighting in common areas, and a Smart Pneumatic Waste Conveyance System. An optional Centralised Cooling System is available, providing energy-efficient cooling without outdoor condensing units. The Optional Component Scheme (OCS) allows elderly buyers of short-lease 2-room Flexi flats to opt for elderly-friendly fittings, with costs added to the flat price.

HDB BTO Flat Type Floor Plans: 2-Room Flexi, 3-Room, 4-Room

Floor plans for four HDB BTO flat types are displayed, each with suggested furniture layouts and approximate floor areas. 2-Room Flexi (Type 1) features one bedroom, living/dining area, kitchen, one bath/WC, a household shelter, and an air-con ledge, with an approximate floor area of 40 sqm (38 sqm internal). 3-Room flats include a main bedroom, one common bedroom, living/dining area, kitchen, service yard, two bath/WCs, a household shelter, and an air-con ledge, totaling approximately 69 sqm (66 sqm internal). 2-Room Flexi (Type 2) offers one bedroom, living/dining area, kitchen, one bath/WC, a household shelter, and an air-con ledge, with an approximate floor area of 47 sqm (45 sqm internal). 4-Room flats comprise a main bedroom, two common bedrooms, living/dining area, kitchen, service yard, two bath/WCs, a household shelter, and an air-con ledge, covering approximately 95 sqm (92 sqm internal).

5-Room Floor Plan with Suggested Furniture Layout

5-room floor plan with a suggested furniture layout. The unit comprises a main bedroom, two additional bedrooms, and two bathrooms (Bath/WC). The common areas include a living/dining space with a suggested study area, a kitchen, a service yard, and a household shelter. An air-con ledge is also indicated. The approximate total floor area for this unit is 113 sqm, which includes an internal floor area of 110 sqm and the air-con ledge.

Residential Site Plan: Block Layouts, Unit Mix, and Amenities

Master plan for a residential development featuring five main blocks: 222A, 224A, 224B, 225A, and 225B. Block heights range from 7 to 16 storeys, with lifts serving every storey. The development offers a total of 789 units, comprising: - 72 units of 2-Room Flexi (Type 1) - 168 units of 2-Room Flexi (Type 2) - 110 units of 3-Room - 284 units of 4-Room - 155 units of 5-Room Key amenities include a 1-storey childcare centre, multi-storey car park, common green spaces, children's playgrounds, and adult/elderly fitness stations. The site plan also indicates future developments like a school, high-rise residential areas, and an MRT line. A scale bar indicates distances up to 100 metres.

Page 12

Block 225B: Unit Mix and Floor Distribution

Building elevation diagram for Block 225B, detailing the distribution of flat types across 15 storeys. Unit types and their floor ranges: - 4-Room flats (yellow): Units 630, 632, available from #01 to #15. - 3-Room flats (orange): Units 634, 636, available from #01 to #15. - 2-Room Flexi (Type 2, darker pink): Units 638, 640, 658, 660, available from #01 to #15. - 2-Room Flexi (Type 1, light pink): - Units 642, 644, 654, 656: Available from #01 to #09. Above these units, from #10 to #15, are 'ROOF GARDEN (ACCESSIBLE)' areas. - Units 646, 648, 650, 652: Available from #01 to #08. Above these units, from #09 to #15, is a 'GREEN ROOF (INACCESSIBLE)' area. The diagram indicates varying building heights for different sections of the block due to the integration of roof gardens and green roofs. This is page 18 of the brochure.

Block 222A: 2nd Storey Floor Plan

2nd storey floor plan for Block 222A, featuring eight residential units. Unit types and numbers on this floor: - 5-Room: Units 530, 532, 534 (3 units) - 4-Room: Units 536, 538, 542, 544 (4 units) - 3-Room: Unit 540 (1 unit) All units include a Living/Dining area, Kitchen, Household Shelter, Service Yard, and at least one Bath/WC. 5-Room units feature a Main Bedroom, two additional bedrooms, and a suggested study area. 4-Room units have a Main Bedroom and two additional bedrooms. 3-Room units comprise a Main Bedroom and one additional bedroom. Common facilities include a central lobby with two lifts, a staircase, a wash area, and centralized refuse chutes. Units at and above the 10th storey are noted to be higher than the main roof garden level of Block 223. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall), while others are standard height.

Block 222A: 3rd-8th and 11th Storey Floor Plans

Floor plans for Block 222A, covering the 3rd to 8th and 11th storeys. The layout features eight residential units per floor, accessible via a common corridor leading to a central lobby with two lifts and a wash area. A centralised refuse chute is also indicated. Unit types available: - 3-Room: Unit 540 (2 bedrooms) - 4-Room: Units 536, 538, 542, 544 (3 bedrooms) - 5-Room: Units 530, 532, 534 (3 bedrooms + suggested study) All units include a living/dining area, kitchen, household shelter, service yard, and at least one bath/WC. Windows are either standard height or 'W1' type (three-quarter height, approx. 550mm high parapet wall). A metric scale bar is provided for reference.

Block 222A: 9th Storey Floor Plans for Multiple Unit Types

Floor plans for Block 222A's 9th storey, featuring a mix of 3-room, 4-room, and 5-room units. Unit types and numbers: - 5-Room: Units 530, 532, 534 (Units 530 and 532 include suggested study areas) - 4-Room: Units 536, 538, 542, 544 - 3-Room: Unit 540 All units include a Main Bedroom, additional Bedrooms, Living/Dining area, Kitchen, Household Shelter, Service Yard, and at least one Bath/WC. Common facilities on this floor include a lobby with two lifts, a wash area, and centralized refuse chutes for general and recyclable waste. A common corridor connects all units. Units at and above the 10th storey are noted to be higher than the main roof garden level of Block 223. Window W1 indicates a three-quarter height window (approx. 550mm high parapet wall), with all other windows being standard height unless specified. The colored floor plan is for illustrative purposes and does not define flat boundaries.

Block 222A: 10th Storey Floor Plan

10th storey floor plan for Block 222A. Unit types available on this floor: - 5-Room flats: Units 530, 532, 534. These units typically include a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, service yard, air-con ledge, and suggested study areas. - 4-Room flats: Units 536, 538, 542, 544. These units feature a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, service yard, and air-con ledge. - 3-Room flat: Unit 540. This unit comprises a main bedroom, one additional bedroom, living/dining area, kitchen, household shelter, two bathrooms, service yard, and air-con ledge. The floor features a common corridor, a lift lobby with two lifts, and a wash area. A centralised refuse chute and a separate chute for recyclable refuse are located near the lifts, with a trellis at the 10th storey only. Units at and above the 10th storey are positioned higher than the main roof garden level of Block 223. Window type W1 indicates a three-quarter height window (approximately 550mm high parapet wall); all other windows are standard height.

Block 222A: 12th Storey Floor Plan with Unit Layouts

12th storey floor plan for Block 222A. Unit types available on this floor include: - 5-Room flats: Units 530, 532, 534. These units feature a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, service yard, two bathrooms, air-con ledge, and a suggested study area. - 4-Room flats: Units 536, 538. These units comprise a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, service yard, two bathrooms, and an air-con ledge. The floor features a common corridor connecting units to a central lift lobby with two lifts, a wash area, and centralised refuse chutes. Two roof gardens are indicated at the 12th storey, accessible from the 13th storey. Units at and above the 10th storey are noted to be higher than the main roof garden level of Block 223. Window W1 is a three-quarter height window (approx. 550mm high parapet wall), while other windows are standard height.

Block 222A: 13th Storey Floor Plan with 4- and 5-Room Units

Floor plan for Block 222A at the 13th storey level. This level features five residential units: - Three 5-Room units (530, 532, 534), each with 3 bedrooms, living/dining area, kitchen, service yard, household shelter, 2 bathrooms, and a suggested study area. - Two 4-Room units (536, 538), each with 3 bedrooms, living/dining area, kitchen, service yard, household shelter, and 2 bathrooms. Common facilities include a central corridor, a lobby with two lifts, stairs, a wash area, and centralised refuse chutes. Units at and above the 10th storey are noted to be higher than the main roof garden level of Block 223. A roof garden is located at the 12th storey and is accessible from the 13th storey. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall), while others are standard height.

Block 222A: 14th Storey Floor Plan

14th storey floor plan for Block 222A. Unit types available on this floor: - 5-Room flats: Units 530, 532, 534. Each includes a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, service yard, and air-con ledge. Units 532 and 534 also feature a suggested study area. - 4-Room flats: Units 536, 538. Each includes a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, service yard, and air-con ledge. Common facilities include a central lobby with lifts, a wash area, and centralized refuse and recyclable refuse chutes. A trellis is indicated at the 14th storey only near Unit 538. Units at and above the 10th storey are noted as being higher than the main roof garden level of Block 223.

Block 222A: 15th & 16th Storey Floor Plan

Floor plan for Block 222A, covering the 15th and 16th storeys. Units at and above the 10th storey are noted as being higher than the main roof garden level of Block 223. The floor features five units: - 5-Room flats: Units 530, 532, 534. Each includes a Main Bedroom, two additional Bedrooms, Living/Dining area, Kitchen, Household Shelter, Service Yard, and two Bath/WCs. Units 530, 532, and 534 also feature a 'Suggested Study' area. - 4-Room flats: Units 536, 538. Each comprises a Main Bedroom, two additional Bedrooms, Living/Dining area, Kitchen, Household Shelter, Service Yard, and two Bath/WCs. Common facilities include a lift lobby with two lifts, a wash area, a centralized refuse chute, and a chute for recyclable refuse, all accessible via a common corridor. A 'Window Legend' indicates 'W1' as a three-quarter height window (approx. 550mm high parapet wall), with other windows being standard height unless specified. The colored plan is for illustration and does not demarcate flat boundaries.

Block 224A: 2nd Storey Floor Plan and Site Features

2nd storey floor plan for Block 224A, featuring a total of 10 residential units. Unit types available on this level: - 3-Room flats: Units 550, 552 (2 units, colored orange) - 4-Room flats: Units 564, 562, 548, 560, 558, 556 (6 units, colored yellow) - 5-Room flats: Units 570, 546 (2 units, colored green), with Unit 570 including a suggested study area. Each unit comprises a living/dining area, kitchen, household shelter, bathrooms (WC and bath), and bedrooms. Service yards and air-con ledges are also present. Common facilities include a lift lobby, wash area, and a centralised refuse chute accessible via common corridors. The plan indicates surrounding structures like a childcare centre roof and a 2nd storey linkbridge. A note clarifies that units at and above the 9th storey are higher than the main roof garden level of Block 223. Window types W1 (three-quarter height) and W2 (standard height with sliding panels) are specified, with all windows defaulting to standard height unless indicated otherwise. A metric scale bar is provided.

Block 224A: 3rd-7th & 10th-12th Storey Floor Plans

Floor plans for Block 224A, covering the 3rd to 7th and 10th to 12th storeys. Units on and above the 9th storey are higher than the main roof garden level of Block 223. Unit types and quantities per floor: - 5-Room flats: Units 546, 566, 568, 570 (4 units). These include a suggested study area, living/dining, kitchen, household shelter, service yard, main bedroom with attached bath, and two additional bedrooms with a common bath. - 4-Room flats: Units 548, 554, 556, 558, 560, 562, 564 (7 units). These feature living/dining, kitchen, household shelter, service yard, main bedroom with attached bath, and two additional bedrooms with a common bath. - 3-Room flats: Units 550, 552 (2 units). These comprise living/dining, kitchen, household shelter, service yard, main bedroom with attached bath, and one additional bedroom with a common bath. The central core includes a lift lobby, wash area, and centralised refuse chute. Window types are indicated by W1 (three quarter height) and W2 (standard height with sliding panels).

Block 224A: 8th Storey Floor Plan

8th storey floor plan for Block 224A, featuring 13 residential units. Unit types and counts: - 5-Room: 4 units (546, 566, 568, 570) - 4-Room: 7 units (548, 554, 556, 558, 560, 562, 564) - 3-Room: 2 units (550, 552) The floor layout includes a central lobby with three lifts, stairs, a wash area, and centralized refuse chutes. A common corridor connects all units. Each unit features a living/dining area, kitchen, household shelter, service yard, bedrooms, and bathrooms. Some 5-room units include a suggested study area. A linkbridge connects to Block 223's multi-storey car park at the 8th storey. Units at and above the 9th storey are higher than Block 223's main roof garden level. Window types W1 (three-quarter height) and W2 (standard height with sliding panels) are indicated.

Block 224A: 9th Storey Floor Plan with 3, 4, and 5-Room Units

Floor plan for Block 224A on the 9th storey, featuring 13 residential units. Unit types available: - 3-Room: Units 550, 552 (2 units) - 4-Room: Units 548, 554, 556, 558, 560, 562, 564 (7 units) - 5-Room: Units 546, 566, 568, 570 (4 units) All units include a living/dining area, kitchen, household shelter, service yard, and at least one bath/WC. 5-Room units feature a suggested study area. The central core provides access to three lifts, a wash area, and a centralised refuse chute. Window types are specified: W1 (three-quarter height, approx. 550mm high parapet wall) and W2 (standard height with additional sliding panels). Units at and above the 9th storey are higher than the main roof garden level of Block 223.

Block 224A: 13th Storey Floor Plan with Unit Layouts

Floor plan for Block 224A, specifically the 13th storey. Units on this level and above the 9th storey are higher than the main roof garden level of Block 223. Unit types available: - 5-Room flats: Units 546, 566, 568, 570. Each includes a living/dining area, kitchen, household shelter, service yard, three bedrooms (one main), and two bathrooms. Some 5-room units feature a suggested study area. - 4-Room flats: Units 558, 560, 562, 564. Each includes a living/dining area, kitchen, household shelter, service yard, three bedrooms (one main), and two bathrooms. Common facilities on this floor include a central lobby with lifts, a wash area, and a centralised refuse chute. Inaccessible green roof areas are also indicated on the 13th storey. Window types are specified: W1 for three-quarter height windows (approx. 550mm high parapet wall) and W2 for standard height windows with additional sliding panels.

Block 224A: 14th Storey Floor Plan

14th storey floor plan for Block 224A, featuring a mix of 4-Room and 5-Room flat types. Unit types and features: - 5-Room flats (Units 568, 566, 570, 546): Each includes a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, and a service yard. Some 5-Room units also feature a suggested study area. - 4-Room flats (Units 564, 562, 560, 558): Each includes a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, and a service yard. Common facilities on this floor include a lift lobby with two lifts, a wash area, a chute for recyclable refuse, and a centralised refuse chute. The units on this floor are higher than the main roof garden level of Block 223. Three inaccessible green roof areas on the 13th storey are also outlined. Window types are specified: W1 (three-quarter height, approx. 550mm high parapet wall) and W2 (standard height with sliding panels).

Block 224A: 15th Storey Floor Plan

Floor plan for Block 224A, specifically for the 15th storey. Unit types and numbers available on this floor: - 5-Room units: 568, 566, 570, 546. These units typically feature 3 bedrooms, living/dining area, kitchen, household shelter, two bathrooms, service yard, and a suggested study area. - 4-Room units: 564, 562, 560, 558. These units typically feature 3 bedrooms, living/dining area, kitchen, household shelter, two bathrooms, and a service yard. The floor layout includes a common corridor, a lift lobby with three lifts, a wash area, and both centralised and recyclable refuse chutes. Important notes: - Units at and above the 9th storey are higher than the main roof garden level of Block 223. - Window types are specified: W1 (three-quarter height window, approx. 550mm high parapet wall) and W2 (standard height window with additional sliding panels). Unless otherwise indicated, all windows are standard height. - The colored floor plan is not intended to demarcate the exact boundary of the flat.

Block 224B: 2nd Storey Floor Plan with Multiple Unit Types

2nd storey floor plan for Block 224B. Unit types available on this floor include: - 2-Room Flexi (Type 1): Units 584, 586, 602. These units feature a living/dining area, one bedroom, one bathroom, a kitchen, and a household shelter. - 2-Room Flexi (Type 2): Units 580, 582, 592, 594, 596, 598, 600. These units also include a living/dining area, one bedroom, one bathroom, a kitchen, and a household shelter. - 3-Room: Units 576, 578. These units comprise a living/dining area, two bedrooms (including a main bedroom), two bathrooms, a kitchen, a household shelter, and a service yard. - 4-Room: Units 572, 574. These units feature a living/dining area, three bedrooms (including a main bedroom), two bathrooms, a kitchen, a household shelter, and a service yard. Common facilities on this floor include multiple lifts, a lobby, common corridors, a wash area, and centralized recyclable refuse chutes. The plan indicates areas with a roof at the 2nd storey only and various void spaces. Window types are specified as W1 (three quarter height) and W2 (standard height with sliding panels). A scale bar indicates measurements in metres.

Block 224B: 3rd-7th Storey Floor Plans

Floor plan for Block 224B, covering levels 3 through 7. Unit types available: - 2-Room Flexi (Type 1): Units 584, 586, 602. These units feature a living/dining area, one bedroom, kitchen, and a bathroom with household shelter. - 2-Room Flexi (Type 2): Units 580, 582, 588, 590, 592, 594, 596, 598, 600. These units feature a living/dining area, one bedroom, kitchen, and a bathroom with household shelter. - 3-Room: Units 576, 578. Each includes a living/dining area, two bedrooms (one main), kitchen, two bathrooms, household shelter, and a service yard. - 4-Room: Units 572, 574. Each includes a living/dining area, three bedrooms (one main), kitchen, two bathrooms, household shelter, and a service yard. Common facilities on this floor include lifts, a lobby, common corridors, a wash area, and centralised recyclable and general refuse chutes. Window types are specified: W1 (three-quarter height) and W2 (standard height with sliding panels).

Block 224B: 8th and 9th Storey Floor Plans

Floor plan layout for Block 224B covering the 8th and 9th storeys. Unit types available include: - 2 Room Flexi (Type 2): Units 596, 598, 600, 582, 580 - 2 Room Flexi (Type 1): Units 586, 584, 602 - 3 Room: Units 576, 578 - 4 Room: Units 572, 574 All units feature a household shelter, kitchen, living/dining area, and at least one bedroom and bathroom. 3-Room and 4-Room units also include a service yard. Common facilities shown are lifts, a lobby, wash area, and centralized refuse chute. Two inaccessible green roof areas are located on the 8th storey. Window types are specified: W1 (three quarter height) and W2 (standard height with sliding panels). The scale indicates measurements up to 10 metres.

Block 224B: 10th-12th Storey Floor Plans

Floor plan layout for Block 224B covering levels 10 through 12. Unit types available: - 2-Room Flexi (Type 1): Units 584, 586, 602 - 2-Room Flexi (Type 2): Units 580, 582, 596, 598, 600 - 3-Room flats: Units 576, 578 - 4-Room flats: Units 572, 574 Each unit includes a living/dining area, bedroom(s), kitchen, bathroom(s), and a household shelter. Some units feature a service yard. Common facilities shown include a common corridor, lift lobby with multiple lifts, a wash area, and centralised refuse chutes (for recyclable and general refuse). Window specifications: - W1: Three-quarter height window (approx. 550mm high parapet wall) - W2: Standard height window with additional sliding panels. Unless otherwise indicated, all windows are standard height. The scale bar indicates measurements in meters, up to 10 meters.

Block 224B: 13th Storey Floor Plan

Floor plan for Block 224B, specifically the 13th storey. Unit types available on this floor: - 2-Room Flexi (Type 1): Unit 602 (1 bedroom, 1 bath/WC, living/dining, kitchen, household shelter). - 2-Room Flexi (Type 2): Units 580, 582 (1 bedroom, 1 bath/WC, living/dining, kitchen, household shelter, service yard). - 3-Room: Units 576, 578 (2 bedrooms, 2 bath/WC, living/dining, kitchen, household shelter, service yard). - 4-Room: Units 572, 574 (3 bedrooms, 2 bath/WC, living/dining, kitchen, household shelter, service yard). Common facilities include lifts, a lobby, wash area, centralized refuse chute, and a chute for recyclable refuse. Three roof gardens are located on the 13th storey, accessible from the 14th storey. Window types are specified: W1 is a three-quarter height window (approx. 550mm high parapet wall), and W2 is a standard height window with additional sliding panels. All other windows are standard height.

Block 224B: 14th Storey Floor Plan and Unit Layouts

14th storey floor plan for Block 224B, featuring seven residential units and common facilities. Unit types and numbers on this floor: - 2-Room Flexi (Type 1): Unit 602 - 2-Room Flexi (Type 2): Units 580, 582 - 3-Room: Units 576, 578 - 4-Room: Units 572, 574 Each unit includes a Living/Dining area, Kitchen, Bath/WC, and Household Shelter. 3-Room and 4-Room units also feature a Service Yard. Common facilities include a lobby, two lifts, a wash area, and a centralised refuse chute. Three roof gardens located on the 13th storey are accessible from this 14th storey. Window types are specified: W1 (three-quarter height, approx. 550mm high parapet wall) and W2 (standard height with additional sliding panels). The scale indicates 10 meters.

Block 224B: 15th Storey Floor Plan with Multiple Unit Types

Floor plan for Block 224B, specifically for the 15th storey. This floor contains seven residential units: - 2-Room Flexi (Type 1): Unit 602 (features a trellis at this storey only) - 2-Room Flexi (Type 2): Units 580, 582 - 3-Room: Units 576, 578 - 4-Room: Units 572, 574 All units include a living/dining area, kitchen, bedroom(s), bath/WC, and household shelter. Common amenities on this floor include a central lobby with two lifts, a common corridor, a wash area, and a centralised refuse chute for recyclable refuse. Window types are specified: W1 is a three-quarter height window (approx. 550mm high parapet wall), and W2 is a standard height window with additional sliding panels. Unless otherwise indicated, all windows are standard height. A scale bar is provided, ranging from 0 to 10 metres.

Block 225A: 2nd Storey Floor Plans

2nd storey floor plan for Block 225A, featuring a mix of 3-Room, 4-Room, and 5-Room residential units. Unit types and counts on this floor: - 5-Room flats: 4 units (604, 624, 626, 628). These include Living/Dining, Kitchen, Household Shelter, Service Yard, 3 Bedrooms, 2 Bath/WC, and some with a 'Suggested Study.' - 4-Room flats: 7 units (606, 612, 614, 616, 618, 620, 622). These include Living/Dining, Kitchen, Household Shelter, Service Yard, 3 Bedrooms, 2 Bath/WC. - 3-Room flats: 2 units (608, 610). These include Living/Dining, Kitchen, Household Shelter, Service Yard, 2 Bedrooms, 2 Bath/WC. The block features a central common area with a lobby, two lifts, staircases, a centralized refuse chute, and a wash area. Specific units on this level are adjacent to or overlook 'ROOF AT 2ND STOREY ONLY' or 'TRELLIS AT 2ND STOREY ONLY' areas. Window types are specified: W1 (three-quarter height) and W2 (standard height with sliding panels), with a general note that all other windows are standard height.

Block 225A: 3rd-12th Storey Floor Plans

Floor plan for Block 225A, covering the 3rd to 12th storeys. Each floor features 13 units, arranged around a central core with a lift lobby, three lifts, a wash area, and a centralised refuse chute. Unit types available per floor include: - 5-Room flats (4 units: 604, 624, 626, 628): Each with 3 bedrooms, 2 bathrooms, and a suggested study area. - 4-Room flats (7 units: 606, 612, 614, 616, 618, 620, 622): Each with 3 bedrooms and 2 bathrooms. - 3-Room flats (2 units: 608, 610): Each with 2 bedrooms and 2 bathrooms. All units are equipped with a living/dining area, kitchen, household shelter, and service yard. Window types are indicated by W1 (three quarter height, approx. 550mm high parapet wall) and W2 (standard height with additional sliding panels). A scale bar indicates measurements up to 10 metres.

Block 225A: 13th Storey Floor Plan with 4-Room and 5-Room Units

13th storey floor plan for Block 225A. Unit types available: - 5-Room flats: Units 604, 624, 626, 628. Each includes 3 bedrooms (one main), 2 bathrooms, living/dining, kitchen, household shelter, service yard, and a suggested study area. - 4-Room flats: Units 616, 618, 620, 622. Each includes 3 bedrooms (one main), 2 bathrooms, living/dining, kitchen, household shelter, and service yard. Common facilities include a central lift lobby with three lifts, a wash area, and centralized refuse chutes. Inaccessible green roof areas are present at the 13th storey. Window types are specified as W1 (three-quarter height) and W2 (standard height with sliding panels).

Block 225A: 14th Storey Floor Plan

Floor plan for Block 225A at the 14th storey. The floor features eight residential units: - Four 5-Room units: Units 604, 624, 626, 628. These units include a living/dining area, kitchen, household shelter, service yard, three bedrooms (one main), two bathrooms, and a suggested study area. - Four 4-Room units: Units 616, 618, 620, 622. These units comprise a living/dining area, kitchen, household shelter, service yard, three bedrooms (one main), and two bathrooms. Common facilities include a central lobby with lifts, a wash area, a centralized refuse chute, and a separate chute for recyclable refuse. External features show inaccessible green roofs located at the 13th storey. Window types are specified: W1 for three-quarter height windows (approx. 550mm high parapet wall) and W2 for standard height windows with additional sliding panels.

Block 225A: 15th Storey Floor Plan

Floor plan for Block 225A on the 15th storey. The floor features eight residential units: - Four 5-Room units (604, 624, 626, 628), each comprising a living/dining area, kitchen, household shelter, service yard, main bedroom with attached bath/WC, two additional bedrooms, and a common bath/WC. Units 604, 624, 626, and 628 include a suggested study area. - Four 4-Room units (616, 618, 620, 622), each with a living/dining area, kitchen, household shelter, service yard, main bedroom with attached bath/WC, two additional bedrooms, and a common bath/WC. A central lift lobby serves the floor with two lifts, a wash area, and both recyclable and centralised refuse chutes. Window types are specified: W1 (three quarter height window, approx. 550mm high parapet wall) and W2 (standard height window with additional sliding panels).

Block 225B: 2nd Storey Floor Plan

2nd storey floor plan for Block 225B, featuring a mix of 2-Room Flexi, 3-Room, and 4-Room units. Unit types and numbers: - 2-Room Flexi (Type 1): Units 642, 644, 660 (red colored) - 2-Room Flexi (Type 2): Units 638, 640, 646, 648, 650, 652, 654, 656, 658 (red colored) - 3-Room: Units 634, 636 (orange colored) - 4-Room: Units 630, 632 (yellow colored) Each unit includes a Living/Dining area, Bedroom(s), Kitchen, Bath/WC, and Household Shelter. Some units also feature a service yard. Common facilities on this floor include a common corridor, lobby, lifts, wash area, and centralized recyclable refuse chutes. Areas marked 'ROOF AT 2ND STOREY ONLY' indicate non-habitable roof spaces at this level. Window types are specified: W1 for three-quarter height windows (approx. 550mm high parapet wall) and W2 for standard height windows with additional sliding panels. All other windows are standard height.

Block 225B: 3rd-7th Storey Floor Plan

Floor plan for Block 225B covering the 3rd to 7th storey. Unit types available include: - 2-Room Flexi (Type 1): Units 642, 644. - 2-Room Flexi (Type 2): Units 638, 640, 646, 648, 650, 652, 654, 656, 658, 660. - 3-Room: Units 634, 636. - 4-Room: Units 630, 632. All units feature a Living/Dining area, Kitchen, Bath/WC, and Household Shelter. 3-Room and 4-Room units also include a Service Yard and an additional Bath/WC. Common facilities on this floor include a common corridor, lift lobby with multiple lifts, a wash area, and both recyclable and centralised refuse chutes. The window legend specifies W1 as a three-quarter height window (approx. 550mm high parapet wall) and W2 as a standard height window with additional sliding panels. Unless otherwise indicated, all windows are standard height.

Block 225B: 8th and 9th Storey Floor Plans

Floor plan for Block 225B, detailing the 8th and 9th storeys. Unit types available on each floor: - 2-Room Flexi (Type 2): Units 638, 640, 654, 656, 658, 660 (6 units) - 2-Room Flexi (Type 1): Units 642, 644 (2 units) - 3-Room: Units 634, 636 (2 units) - 4-Room: Units 630, 632 (2 units) Each 2-Room Flexi unit includes a living/dining area, bedroom, kitchen, bath/WC, and household shelter. Some Type 2 units also feature a service yard. 3-Room units comprise a living/dining area, main bedroom, one additional bedroom, kitchen, bath/WC, household shelter, and service yard. 4-Room units feature a living/dining area, main bedroom, two additional bedrooms, kitchen, bath/WC, household shelter, and service yard. Common facilities include a lift lobby, wash area, common corridor, and centralized refuse chutes. Inaccessible green roof areas are indicated at the 8th storey. A scale bar is provided for reference.

Block 225B: 10th to 12th Storey Floor Plan

Floor plan for Block 225B, covering the 10th to 12th storeys. Unit types available: - 2-Room Flexi (Type 1): Units 642, 644, 660. These units include a living/dining area, one bedroom, kitchen, bath/WC, and household shelter. - 2-Room Flexi (Type 2): Units 638, 640, 654, 656, 658. These units also feature a living/dining area, one bedroom, kitchen, bath/WC, and household shelter. - 3-Room: Units 634, 636. These units have a living/dining area, two bedrooms (one main), kitchen, bath/WC, household shelter, and service yard. - 4-Room: Units 630, 632. These units feature a living/dining area, three bedrooms (one main), kitchen, two bath/WCs, household shelter, and service yard. Common facilities include common corridors, a central lift lobby with two lifts, a wash area, and a centralised refuse chute with a dedicated chute for recyclable refuse. Window specifications: W1 indicates a three-quarter height window (approx. 550mm high parapet wall), and W2 denotes a standard height window with additional sliding panels. Unless otherwise indicated, all windows are standard height. Units are color-coded: 2-Room Flexi in pink/red, 3-Room in orange, and 4-Room in yellow.

Block 225B: 13th Storey Floor Plan

Floor plan for Block 225B, specifically for the 13th storey. The floor features seven residential units: - 2-Room Flexi (Type 1): Unit 660 - 2-Room Flexi (Type 2): Units 638, 640 - 3-Room: Units 634, 636 - 4-Room: Units 630, 632 Common facilities include lift lobbies, a common corridor, a wash area, a centralised refuse chute, and a chute for recyclable refuse. Each unit typically includes a living/dining area, kitchen, bathroom(s), bedroom(s), and a household shelter. Some units also feature a service yard and air-con ledge. Roof gardens are located on the 13th storey, accessible from the 14th storey. Window types are specified: W1 (three quarter height, approx. 550mm high parapet wall) and W2 (standard height with additional sliding panels). A metric scale bar from 0 to 10 metres is provided.

Block 225B: 14th Storey Floor Plan

14th storey floor plan for Block 225B. Unit types available on this floor: - 2-Room Flexi (Type 1): Unit 660 (1 bedroom, 1 bath/WC, living/dining, kitchen, household shelter) - 2-Room Flexi (Type 2): Units 638, 640 (1 bedroom, 1 bath/WC, living/dining, kitchen, household shelter) - 3-Room: Units 634, 636 (2 bedrooms, 2 bath/WC, living/dining, kitchen, household shelter, service yard, AC ledge) - 4-Room: Units 630, 632 (3 bedrooms, 2 bath/WC, living/dining, kitchen, household shelter, service yard, AC ledge) The floor features a central lobby with lifts, a wash area, and a common corridor. Centralised and recyclable refuse chutes are provided. Roof gardens on the 13th storey are accessible from the 14th storey. Window types are specified: W1 for three-quarter height (approx. 550mm high parapet wall) and W2 for standard height with additional sliding panels. The scale bar indicates measurements in metres.

Block 225B: 15th Storey Floor Plan with Multiple Unit Types

15th storey floor plan for Block 225B, featuring a mix of 2-Room Flexi, 3-Room, and 4-Room units. Unit types and their configurations: - 2-Room Flexi (Type 1): Unit 660, includes 1 bedroom, 1 bath/WC, kitchen, living/dining, and household shelter. - 2-Room Flexi (Type 2): Units 638 and 640, each with 1 bedroom, 1 bath/WC, kitchen, living/dining, household shelter, and service yard. - 3-Room: Units 634 and 636, each with 2 bedrooms, 2 bath/WC, kitchen, living/dining, household shelter, and service yard. - 4-Room: Units 630 and 632, each with 3 bedrooms, 2 bath/WC, kitchen, living/dining, household shelter, and service yard. The floor features a central lobby with two lifts and a staircase, along with a wash area and centralised refuse chute. A trellis is indicated specifically for the 15th storey. Window types are specified as W1 (three quarter height) and W2 (standard height with sliding panels).

General Specifications for 2-Room Flexi (Short Lease) Units

General specifications for 2-room Flexi (short lease) units at Garden Terrace @ Tengah. **Construction Details:** - **Foundation:** Piled foundations. - **Structure:** Reinforced concrete structural framework with reinforced concrete slabs. - **Roof:** Reinforced concrete roof slab with precast concrete secondary roofing. - **Walls:** External and internal walls are constructed with reinforced concrete, precast panels, drywall partition system, or precast lightweight concrete partitions. - **Windows:** Aluminium framed with tinted glass. **Doors:** - **Entrance:** Laminated timber door and metal gate. - **Bedroom:** Laminated UPVC sliding partition/door (where applicable). - **Bathroom/WC:** Laminated UPVC folding door. - **Household Shelter:** Metal door. **Finishes:** - **Living/Dining/Bedroom Floor:** Vinyl strip flooring with laminated UPVC skirting. - **Kitchen/Bathroom/WC/Household Shelter Floor:** Glazed porcelain tiles. - **Kitchen/Bathroom/WC Walls:** Glazed porcelain tiles. - **Ceilings/Other Walls:** Skim coated or plastered and painted. **Fittings:** - Standard: Quality locksets, water closet suite, clothes drying rack, grab bars, wash basin with tap mixer, bath/shower mixer with shower set. - Optional: Built-in kitchen cabinets with induction hob and cooker hood, kitchen sink, dish drying rack, built-in wardrobe, window grilles, water heater, lighting. **Services:** - Gas services, concealed water supply pipes, exposed sanitary stacks at air-con ledge. - Concealed electrical wiring for lighting, power points (including water heater and air-conditioning points), television points, data points. **Important Notes:** - Household Shelter is for civil defence and cannot be altered. - Laminated UPVC door frames are provided for all Bedroom and Bathroom/WC openings. - Unused open spaces adjacent to units are not for purchase or enclosure. - Details of services (gas, water, electrical, TV, data) are not indicated on plans.

General Specifications for HDB Flat Types

This page details general specifications for 2-room Flexi, 3-room, 4-room, and 5-room HDB BTO flats. **Building Structure**: Piled foundations, reinforced concrete framework, reinforced concrete roof slab with precast secondary roofing. Walls are reinforced concrete, precast panels, drywall, or lightweight concrete partitions. Windows are aluminium framed with tinted glass. **Doors**: Entrance has laminated timber door and metal gate. Bedrooms have laminated UPVC doors. 2-room Flexi units may have UPVC sliding partitions. Bathroom/WC doors are laminated UPVC folding, Household Shelters have metal doors, and Service Yards have aluminium framed doors with glass. **Finishes**: Living/Dining floors feature polished porcelain tiles with UPVC skirting; Bedrooms have vinyl strip flooring with UPVC skirting. Kitchen, Bathroom/WC, Household Shelter, and Service Yard floors are glazed porcelain tiles. Walls are glazed porcelain tiles or skim coated/painted. **Fittings & Services**: Standard fittings include quality locksets, water closet suite, clothes drying rack, and bathroom fixtures. Services provided are gas, concealed water supply, exposed sanitary stacks, concealed electrical wiring (lighting, power, water heater, air-conditioning), television, and data points. **Important Notes**: Household Shelters are civil defence shelters and cannot be altered. Unused open spaces are not for purchase. Service details are not on plans. Renovation rules are on HDB's website.

HDB BTO Brochure General Disclaimer

This page presents the general disclaimer for an HDB BTO brochure. HDB owns copyright for all brochure content, which is for general information only and not an offer or contract. Visuals are artistic impressions, not factual. All project information, including dimensions, plans, and specifications, is subject to change without notice or by authorities. HDB reserves the right to alter project amenities, facilities, and design features. Layout alterations for individual needs are not entertained. Accuracy of information is not warranted, and HDB is not liable for reliance on it. Floor areas are scaled strata areas, subject to final survey. Surrounding land use and facilities are indicative and subject to change. HDB reserves the right to use void decks, car parks, common property (e.g., precinct pavilions), and standalone community buildings for various purposes, including future amenities (childcare, elderly, education centers), commercial facilities (shops, eating houses), and mechanical/electrical rooms. This brochure is not comprehensive; users are advised to contact relevant authorities for full details. Page 55. Copyright Housing & Development Board, November 2020.

Optional Component Scheme for 2-Room Flexi Flats

This page outlines the Optional Component Scheme (OCS) for 2-room Flexi flats in Garden Court @ Tengah and Garden Terrace @ Tengah. The OCS is an opt-in scheme, with costs added to the flat's selling price. 2-room Flexi flats are offered on either a 99-year or short-lease. Standard inclusions for all 2-room Flexi flats are: - Floor finishes in living/dining room, bedroom, kitchen, household shelter, and bathroom. - Wall tiles in kitchen and bathroom. - Sliding partition/door for bedroom; folding bathroom door. - Sanitary fittings including wash basin with tap mixer, shower set with bath/shower mixer, and water closet suite. For short-lease flats, grab bars will be installed to assist elderly buyers. Visuals show examples of a shower set, a wash basin, and grab bars with light switches. The information is for reference and subject to change, dated November 2020.

Optional Component Scheme for 2-Room Flexi Flats

This page outlines the Optional Component Scheme (OCS) for short-lease 2-Room Flexi flats, designed for elderly buyers seeking move-in ready units. **Elderly Friendly Fittings include:** - Built-in kitchen cabinets with induction hob, cooker hood, sink, tap, and dish drying rack. - Induction hob features: no open flame, faster cooling, easier cleaning, and flat surface to prevent toppling. - Mobile kitchen cabinets providing knee space, especially for wheelchair users. - Built-in bedroom wardrobe with a lower clothes hanging rod for easy reach. - Option for lower counter top height: - Option A (Default): Bottom cabinet at 850mm, Top cabinet at 1500mm (from floor level). - Option B: Bottom cabinet at 800mm, Top cabinet at 1200mm (from floor level), suitable for wheelchair-bound residents. **Other Fittings include:** - Window grilles for safety and security. - Mirror. - Toilet roll holder. - Lighting. - Water heater. The cost of this OCS package will be added to the selling price of the selected flat. All displays are for reference and subject to change.
