Vanda Breeze @ Yishun

HDB BTO Project Sales Launch Information

Introductory page for the Vanda Breeze @ Yishun HDB BTO project. The page announces HDB's Sales Launch in November 2022. It features an artist's impression of the residential blocks, characterized by green and grey facades, set amidst lush landscaping. A graphic of purple orchids accompanies the project name 'Vanda Breeze @ Yishun'. The lower section includes a photograph of two smiling individuals, a man and a woman, facing forward with arms crossed.

HDB BTO Project Overview and Details

Overview of the Vanda Breeze @ Yishun HDB BTO project. The development consists of 10 residential blocks, each 14 storeys in height. Two of these blocks are designated to house rental flats. A total of 961 units are available, comprising 2-room Flexi, 3-room, 4-room, and 5-room flat types. The project is situated within an area bounded by Yishun Avenue 1, Yishun Street 53, and Yishun Avenue 10. The design incorporates lush landscaping, a green leafy theme, and orchid motifs, drawing inspiration from Singapore's national flower, the Vanda Miss Joaquim. Nearby developments like Aranda Breeze @ Yishun and Miltonia Breeze @ Yishun are also named after orchid species. The visual representation is an artist's impression of the completed development.

Artist's Impression: Residential Amenities & Greenery

Artist's impression of a residential development highlighting its integrated amenities and green environment. The development features multi-storey residential blocks with green and grey facade designs. Key recreational facilities and communal spaces include: - A large central lawn for open play and activities. - Children's playgrounds equipped with slides and climbing structures. - Designated fitness stations. - Landscaped areas with walking paths, trees, and shrubs. Additional amenities mentioned in the accompanying text are: - An eating house, supermarket, and various shops. - A childcare centre. - A residents' network centre. - A roof garden situated above the Multi-Storey Car Park. - An adjacent park. All facilities within this development are designed to be accessible by the public.

Important Notes on HDB Precinct Amenities and Noise Levels

This page, titled 'IMPORTANT NOTES' for the Vanda Breeze @ Yishun project, provides key information regarding HDB precincts and potential living conditions. HDB precincts are designed to include various amenities and facilities to serve the community's evolving needs. These include childcare centers, elderly-related facilities, education centers, residents' network centers, day activity centers, commercial facilities (shops, eating houses), and mechanical/electrical rooms. These spaces may be located within void decks, common property, car parks, or standalone community buildings. Additionally, housing projects may be situated near areas such as roads, railways, airbases, or land designated for non-residential purposes, which could lead to higher noise levels for residents. Information provided on surrounding land use and proposed facilities is indicative, based on current planning intent, and is subject to change over time.

Yishun Area Amenities Map

Locality map for the Yishun area, highlighting the Vanda Breeze @ Yishun project site in yellow, located near Lower Seletar Reservoir. Key transportation nodes include Yishun MRT Station and Khatib MRT Station, with major roads like Yishun Avenue and Yishun Ring Road. Educational institutions shown are Yishun Primary, Northland Primary, North View Primary, Chung Cheng High School (Yishun), and other primary/secondary schools, alongside MOE Kindergartens (MK) and schools under construction (u/c). Healthcare facilities comprise Khoo Teck Puat Hospital, Yishun Community Hospital, Yishun Polyclinic, and proposed health & medical care sites. Commercial and recreational amenities include Northpoint City/North Park Residences, Yishun Mall, Junction Nine, Wisteria Mall, SAFRA Yishun Country Club, Orchid Country Club Golf Course (Interim), Yishun Pond, and various parks and park connectors. Civic and community facilities feature Nee Soon East Community Club, Yishun Intergrated Transport Hub, and proposed civic & community institutions. Notes indicate that all proposed developments and facilities are indicative and subject to change and planning approval. Civic & Community Institutions may include community centres, associations, and homes for the aged. Health & Medical Care can include hospitals, polyclinics, clinics, nursing homes, and eldercare facilities. Ancillary uses like columbariums within places of worship and childcare centres within community centres are possible. The map includes a scale bar from 0 to 500 metres.

Property Features, Fittings, and Smart Home Solutions

This brochure page outlines the eco-friendly features, interior finishes, smart solutions, and an optional component scheme for the Vanda Breeze @ Yishun development. **Eco-Friendly Features:** - Separate chutes for recyclable waste - Regenerative lifts for energy efficiency - Bicycle stands - Parking spaces with provisions for electric vehicle charging stations - Use of sustainable products - Active, Beautiful, Clean Waters (ABC Waters) design features **Finishes and Fittings:** - **2-Room Flexi:** Vinyl strip flooring in living/dining and bedroom; floor tiles in bathroom, household shelter, and kitchen; wall tiles in bathroom and kitchen. Includes a sliding partition/door for the bedroom, folding bathroom door, standard sanitary fittings (wash basin, shower set, water closet suite), and grab bars for short-lease units. - **3-, 4- and 5-Room:** Vinyl strip flooring in living/dining and bedrooms; floor tiles in bathrooms, household shelter, kitchen/utility (3-room), and kitchen/service yard (4- and 5-room); wall tiles in bathrooms, kitchen/utility (3-room), and kitchen (4- and 5-room). Includes internal doors for bedrooms and folding doors for bathrooms, and standard sanitary fittings. **Smart Solutions:** - Smart-Enabled Homes with provisions for smart home solutions - Smart Lighting in common areas - Smart Pneumatic Waste Conveyance System **Optional Component Scheme (OCS):** - Available for elderly buyers of short-lease 2-room Flexi flats, offering elderly-friendly and other fittings. The cost of OCS components is added to the flat price.

HDB BTO 2-Room Flexi Floor Plan Layout Ideas: Type 1 & Type 2

Floor plan layout ideas for 2-Room Flexi units. **2-Room Flexi (Type 1)**: - Approx. Floor Area: 40 sqm - Internal Floor Area: 38 sqm - Includes: Bedroom, Living/Dining area, Kitchen, Bath/WC, Household Shelter, Air-con Ledge. **2-Room Flexi (Type 2)**: - Approx. Floor Area: 49 sqm - Internal Floor Area: 47 sqm - Includes: Bedroom, Living/Dining area, Kitchen, Bath/WC, Household Shelter, Air-con Ledge. - One variant shows an optional folding door for short lease. The 47-sqm 2-room Flexi flats offer flexible space for various uses such as dining, a study, or an extra bed.

HDB BTO Floor Plan Layout Ideas for Multiple Flat Types

This page presents suggested floor plan layouts for 3-room, 4-room, and 5-room HDB BTO flats, including approximate and internal floor areas. The 3-room floor plan has an approximate area of 71sqm (68sqm internal) and features a Main Bedroom, one additional Bedroom, Living/Dining area, two Bath/WCs, Household Shelter, and a combined Kitchen/Utility space. A dotted line indicates a suggested partition to separate the utility area. The 4-room floor plan is approximately 95sqm (92sqm internal) and includes a Main Bedroom, two additional Bedrooms, Living/Dining area, two Bath/WCs, Household Shelter, Kitchen, and a Service Yard. The 5-room floor plan measures approximately 113sqm (110sqm internal) and comprises a Main Bedroom, two additional Bedrooms, a suggested Study area, Living/Dining, two Bath/WCs, Household Shelter, Kitchen, and a Service Yard. All layouts include suggested furniture placements and an Air-con Ledge. The design emphasizes flexibility in kitchen space, allowing homeowners to configure the area to their preferences.

HDB BTO Site Plan with Block Layouts and Unit Mix

Comprehensive site plan for a HDB BTO development, detailing the layout of ten residential blocks: 522A, 522B, 522C, 523A, 523B, 524A, 524B, 524C, 524D, and 524E. All blocks are 14 storeys high. The development offers a total of 987 units, comprising: - 26 Rental 2-Room flats - 78 Home Ownership 2-Room Flexi (Type 1) - 260 Home Ownership 2-Room Flexi (Type 2) - 91 Home Ownership 3-Room flats - 285 Home Ownership 4-Room flats - 247 Home Ownership 5-Room flats Key amenities and facilities include: - Play facilities: Children playground, adult and elderly fitness stations, hardcourt. - Communal areas: Precinct pavilion, drop-off porch. - Social amenities (all at 1st storey): Eating house, supermarket, shops, childcare centre, residents' network centre. - A 5/6 storey multi-storey carpark with a roof garden. - Linkbridges at the 9th storey. - Essential services like Electrical Sub-Station (ESS), Utility Centre (UC), Bin Center (BC), and a Centralised Refuse Chute system. The site is bordered by Yishun Avenue 1, Yishun Avenue 6, and future roads Yishun Street 53 and Yishun Avenue 10. Adjacent to XCL World Academy and reserved sites for drainage, park, and future high-rise development.

Unit Distribution for Blocks 522A, 522B, 522C, and 523A, Floors 1-14

Unit distribution across Blocks 522A, 522B, 522C, and 523A, detailing available flat types from floors #01 to #14. Block 522A offers 4-Room flats (units 100, 102, 104, 106) and 2-Room Flexi (Type 2) flats (units 108, 110, 112). Unit 102 on the 1st storey is designated as a 'RESIDENTS' NETWORK CENTRE'. Block 522B includes 3-Room flats (unit 114), 2-Room Flexi (Type 2) flats (units 116, 118, 120, 122), and 4-Room flats (units 124, 126). Block 522C features 2-Room Flexi (Type 2) flats (units 128, 130, 134), 3-Room flats (unit 132), and 4-Room flats (units 136, 138). Block 523A provides 4-Room flats (units 140, 142, 144, 146), 3-Room flats (unit 148), and 2-Room Flexi (Type 2) flats (units 150, 152, 154, 156). The 1st storey of units 140, 142, 144, and 146 are marked as 'FUTURE AMENITIES / FACILITIES'. All residential units span from the 2nd to 14th storey, with ground floor units often reserved for communal facilities.

Unit Distribution: Blocks 523B, 524A, 524B, 524C (Floors 1-14)

This page details the unit distribution for HDB BTO Blocks 523B, 524A, 524B, and 524C, across 14 storeys from floor #01 to #14. Block 523B offers 3-Room (units 166, 168) and 4-Room (units 158, 160, 162, 164, 170, 172) flats. Units 158-164 on the 1st storey are designated for future amenities/facilities. Block 524A includes 3-Room (units 188, 190), 4-Room (units 174, 178, 180, 182, 186, 192), and 5-Room (units 176, 184) flats. Block 524B features 3-Room (unit 194) and 5-Room (units 196, 198, 200, 202, 204, 206) flats. Block 524C provides 2-Room Flexi (Type 2) (units 214, 216, 218, 220), 4-Room (unit 208), and 5-Room (units 210, 212) flats. All blocks are 14 storeys high, with units available from the 1st floor, except for specific units in Block 523B.

Unit Distribution for Blocks 524D and 524E, Floors #01-#14

Unit distribution for Blocks 524D and 524E, each 14 storeys high, showing flat types by stack and floor. Block 524D: - Stacks 222, 224: 4-Room flats (Stack 222 from #02 to #14, Stack 224 from #01 to #14). - Stacks 226, 228, 230, 232, 234, 236: 2-Room Flexi (Type 2) flats (all from #01 to #14). Block 524E: - Stacks 238, 240, 246: 4-Room flats (all from #01 to #14). - Stacks 242, 244: 2-Room Flexi (Type 2) flats (all from #01 to #14). - Stack 248: 5-Room flats (from #01 to #14). - Stack 250: 3-Room flats (from #01 to #14). No rental units or 2-Room Flexi (Type 1) units are present in these two blocks based on the provided diagrams.

Block 522A: 2nd Storey Floor Plan

2nd storey floor plan for Block 522A. Unit types available on this floor include: - Two 5-Room units (Units 102 and 104), each featuring a main bedroom, two additional bedrooms, a suggested study area, living/dining space, kitchen, household shelter, two bathrooms, service yard, and air-con ledge. - Three 2-Room Flexi (Type 2) units (Units 108, 110, and 112), each with one bedroom, living/dining area, kitchen, household shelter, one bathroom, and air-con ledge. - One un-numbered Rental Flat. Common facilities include a central lobby with lifts, a common corridor, a void area, a wash area, and both recyclable and centralised refuse chutes. Several areas indicate 'ROOF AT 2ND STOREY ONLY'. Windows marked 'W1' are three-quarter height with an approximate 550mm high parapet wall. All other windows are standard height unless indicated.

Block 522A: 3rd to 14th Storey Floor Plan

Floor plan for Block 522A, applicable to the 3rd to 14th storeys. The floor features a mix of unit types: - Two 5-Room units (102, 104): Each includes a main bedroom, two additional bedrooms, a suggested study area, living/dining, kitchen, two bathrooms, household shelter, service yard, and air-con ledge. - One 4-Room unit (100): Comprises a main bedroom, two additional bedrooms, living/dining, kitchen, two bathrooms, household shelter, service yard, and air-con ledge. - Three 2-Room Flexi (Type 2) units (108, 110, 112): Each has one bedroom, living/dining, kitchen, one bathroom, household shelter, and air-con ledge. - One Rental Flat is also shown on this level. Common facilities include a central lobby with two lifts, a common corridor, a chute for recyclable refuse, a wash area, and a centralised refuse chute. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall).

Block 522B: 2nd Storey Floor Plan

2nd storey floor plan for Block 522B, featuring a total of seven residential units. Unit types and their features: - Two 4-Room units (124, 126) each with a main bedroom, two common bedrooms, living/dining area, kitchen, household shelter, service yard, and two bathrooms. - One 3-Room unit (114) with a main bedroom, one common bedroom, living/dining area, kitchen/utility, household shelter, and two bathrooms. - Four 2-Room Flexi (Type 2) units (116, 118, 120, 122) each with one bedroom, living/dining area, kitchen, household shelter, and one bathroom. Common facilities include a central lobby, lifts, centralized refuse chute, and a wash area. Some sections of the floor plan indicate 'ROOF AT 2ND STOREY ONLY'. A window legend specifies 'W1' as a three-quarter height window (approx. 550mm high parapet wall). The colored floor plan is not intended to demarcate the boundary of the flat.

Block 522B: 3rd-8th, 11th-14th Storey Floor Plans

Floor plans for Block 522B, covering the 3rd to 8th and 11th to 14th storeys. Unit types and numbers shown: - 4-Room flats: Units 124, 126. Each includes a main bedroom, two additional bedrooms, living/dining area, kitchen, household shelter, two bathrooms, and a service yard. - 3-Room flat: Unit 114. Features a main bedroom, one additional bedroom, living/dining area, kitchen/utility, household shelter, and two bathrooms. - 2-Room Flexi (Type 2) flats: Units 116, 118, 120, 122. Each includes one bedroom, living/dining area, kitchen, household shelter, and one bathroom. The common area includes a lobby with lifts, a wash area, a centralised refuse chute, and a chute for recyclable refuse. A common corridor connects the units. Units at the 12th storey and above are noted to be higher than Block 522. Window legend indicates W1 as a three-quarter height window (approx. 550mm high parapet wall).

Block 522B: 9th Storey Floor Plan

Floor plan for Block 522B, specifically the 9th storey, showing a total of seven residential units. Unit types available on this floor include: - Two 4-Room units (124, 126), each with three bedrooms (including main), two bathrooms, living/dining area, kitchen, household shelter, and service yard. - One 3-Room unit (114), featuring two bedrooms (including main), two bathrooms, living/dining area, kitchen/utility, and household shelter. - Four 2-Room Flexi (Type 2) units (116, 118, 120, 122), each with one bedroom, one bathroom, living/dining area, kitchen, and household shelter. The central common area provides access to lifts, a wash area, and both centralised and recyclable refuse chutes. A linkbridge connects Block 522B to Block 522 at this 9th storey level. Units from the 12th storey upwards in Block 522B are noted to be higher than those in Block 522. All units include a household shelter and air-con ledge. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall).

Block 522B: 10th Storey Floor Plan

10th storey floor plan for Block 522B. Unit types available on this floor: - 4-Room flats: Units 124, 126 - 3-Room flat: Unit 114 - 2-Room Flexi (Type 2) flats: Units 116, 118, 120, 122 The floor features a central common area with lifts, a lobby, a wash area, and both centralised and recyclable refuse chutes. Each unit includes a household shelter, kitchen, living/dining area, and bath/WC. 4-Room units also have a service yard. A roof is indicated at the 10th storey level above the common area. Units at the 12th storey and above are noted to be higher than Block 522. Windows marked W1 are three-quarter height (approx. 550mm high parapet wall).

Block 522C: 2nd to 14th Storey Floor Plans

Floor plan layout for Block 522C covering levels 2 through 14. Unit types available: - 3 Room: Unit 132 - 2 Room Flexi (Type 2): Unit 134 - 2 Room Flexi (Type 1): Units 128, 130 - 5 Room: Units 136, 138 All units include a household shelter, kitchen, living/dining area, and at least one bathroom. The 3 Room unit features two bedrooms. The 2 Room Flexi units feature one bedroom. The 5 Room units feature a main bedroom, two additional bedrooms, a service yard, and a suggested study area. Common facilities include a lift lobby with two lifts, a wash area, and centralized refuse chutes. Specific areas are designated as 'ROOF AT 2ND STOREY ONLY'. Windows marked W1 are three-quarter height (approx. 550mm high parapet wall).

Block 523A: 2nd to 14th Storey Floor Plan

Floor plan for Block 523A, covering the 2nd to 14th storeys. Unit types available on these floors include: - 2-Room Flexi (Type 2): Units 150, 152, 154, 156. Each features one bedroom, living/dining area, kitchen, household shelter, and bath/WC. - 3-Room: Unit 148. Includes one bedroom, one main bedroom, living/dining area, kitchen/utility, household shelter, and two bath/WCs. - 4-Room: Units 140, 142, 144, 146. Each typically comprises three bedrooms (including a main bedroom), living/dining area, kitchen, household shelter, and two bath/WCs. Units 140, 142, 144, and 146 also include a service yard. The units are arranged around a central common corridor with a lift lobby, wash area, centralised refuse chute, and chute for recyclable refuse. Areas marked 'ROOF AT 2ND STOREY ONLY' indicate specific structural elements at that level. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall).

Block 523B: 2nd to 14th Storey Floor Plan

Floor plan for Block 523B, covering the 2nd to 14th storeys. The layout for each floor includes eight residential units: - One 5-Room unit (Unit 166) with a suggested study area. - One 3-Room unit (Unit 168) with a kitchen/utility area. - Six 4-Room units (Units 158, 160, 162, 164, 170, 172). All units are equipped with a Main Bedroom, additional bedrooms, Living/Dining area, Kitchen, Bath/WC, Household Shelter, Service Yard, and Air-con Ledge. Common facilities include a central lobby with two lifts, a wash area, and a centralised refuse chute. Units 158, 160, 162, 164, 170, and 172 are noted to have a 'ROOF AT 2ND STOREY ONLY' adjacent to them, indicating a specific roof structure at that level. Windows marked 'W1' are three-quarter height, approximately 550mm high parapet wall. Other windows are standard height unless indicated.

Block 524A: 2nd-14th Storey Floor Plans

Floor plan layout for Block 524A covering levels 2 through 14. Unit types available: - 3-Room: Unit 190 (only on 2nd storey, includes kitchen/utility) - 4-Room: Units 178, 180, 186, 188 (Units 186 & 188 only on 2nd storey) - 5-Room: Units 174, 176, 182, 184, 192 (Unit 192 only on 2nd storey) All units feature a living/dining area, kitchen, household shelter, service yard, air-con ledge, and at least two bathrooms. 5-Room units include a 'suggested study' area. Common facilities shown are a common corridor, lobby with two lifts, a wash area, and centralized refuse chutes. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall). Unless otherwise indicated, all windows are standard height.

Block 524B: 2nd to 14th Storey Floor Plans

Floor plans for Block 524B, applicable for the 2nd to 14th storeys. Unit types available: - 5-Room: Units 204, 198, 196. Each features a main bedroom, two additional bedrooms, a suggested study area, living/dining, kitchen, two bathrooms, a household shelter, and a service yard. - 4-Room: Units 206, 202, 200. Each includes a main bedroom, two additional bedrooms, living/dining, kitchen, two bathrooms, a household shelter, and a service yard. Units 200 and 202 also indicate a suggested study area within the living/dining space. - 3-Room: Unit 194. Comprises a main bedroom, one additional bedroom, living/dining, kitchen/utility, two bathrooms, and a household shelter. Common facilities on each floor include a lift lobby, a centralized refuse chute with a wash area, and access to a common corridor. Areas marked 'ROOF AT 2ND STOREY ONLY' indicate specific structural elements or lower roof sections. Windows labeled 'W1' are three-quarter height (approx. 550mm high parapet wall).

Block 524C: 2nd to 14th Storey Floor Plans

Floor plan for Block 524C, covering levels 2 through 14. Unit types available: - 2 Room Flexi (Type 2): Units 218, 220. Each includes a bedroom, living/dining area, kitchen, bath/WC, and household shelter. - 2 Room Flexi (Type 1): Units 216, 214. Each includes a bedroom, living/dining area, kitchen, bath/WC, and household shelter. - 4 Room: Unit 208. Features a main bedroom, two additional bedrooms, living/dining area, kitchen, bath/WC, household shelter, service yard, and air-con ledge. - 5 Room: Units 212, 210. Each features a main bedroom, two additional bedrooms, a suggested study area, living/dining area, kitchen, bath/WC, household shelter, service yard, and air-con ledge. Common facilities shown include lifts, a lobby, centralised refuse chute, wash area, and a chute for recyclable refuse, all accessible via a common corridor. Some areas are marked as "ROOF AT 2ND STOREY ONLY". The window legend indicates W1 as a three-quarter height window (approx. 550mm high parapet wall).

Block 524D: 2nd to 14th Storey Floor Plans

Floor plans for Block 524D, applicable from the 2nd to 14th storey. Unit types shown include: - 2-Room Flexi (Type 1): Units 228, 230, each with 1 bedroom, living/dining, kitchen, bath/WC, and household shelter. - 2-Room Flexi (Type 2): Units 232, 234, 236, each with 1 bedroom, living/dining, kitchen, bath/WC, and household shelter. - 4-Room: Unit 222, featuring 3 bedrooms (including a main bedroom), living/dining, kitchen, 2 bath/WCs, household shelter, service yard, and air-con ledge. - 5-Room: Units 224, 226, each with 3 bedrooms (including a main bedroom), living/dining, kitchen, 2 bath/WCs, household shelter, service yard, air-con ledge, and a suggested study area. Common facilities such as the lift lobby, lifts, wash area, centralised refuse chute, and recyclable refuse chute are located at the 2nd storey only. Areas marked "ROOF AT 2ND STOREY ONLY" indicate open-to-sky spaces above the second floor. Windows indicated as W1 are three-quarter height (approx. 550mm high parapet wall), while others are standard height.

Block 524E: 2nd Storey Floor Plan with Multiple Unit Types

2nd storey floor plan for Block 524E. Unit types and numbers: - 2-Room Flexi (Type 2): Units 242, 244, 248. Unit 248 is adjacent to a Rental Flat. - 3-Room: Unit 250. - 5-Room: Units 238, 240. Common facilities include a lift lobby, common corridor, wash area, centralised refuse chute, and chute for recyclable refuse. Certain areas are indicated as "ROOF AT 2ND STOREY ONLY". Each 2-Room Flexi unit features a living/dining area, one bedroom, kitchen, household shelter, and a bath/WC. The 3-Room unit includes a main bedroom, one additional bedroom, living/dining area, kitchen/utility, household shelter, and two bath/WCs. The 5-Room units comprise a main bedroom, two additional bedrooms, living/dining area, kitchen, service yard, household shelter, two bath/WCs, and a suggested study area. Windows marked 'W1' are three-quarter height (approx. 550mm high parapet wall). Units at the 12th storey and above are noted to be higher than Block 522.

Block 524E: 3rd-8th, 11th-14th Storey Floor Plans

Floor plan for Block 524E, covering the 3rd to 8th and 11th to 14th storeys. Unit types shown include: - 2-Room Flexi (Type 2): Units 242, 244, and 248. Unit 248 is adjacent to a 'Rental Flat'. - 3-Room: Unit 250. - 5-Room: Units 238 and 240. All units feature a living/dining area, kitchen, household shelter, and at least one bath/WC. The 5-Room units include a service yard and a suggested study area. The 3-Room unit has two bedrooms and two bathrooms. Common facilities include a common corridor, lift lobby with two lifts, a staircase, a wash area, and both recyclable and centralised refuse chutes. Units at the 12th storey and above are noted to be higher than Block 522. Window W1 indicates a three-quarter height window (approx. 550mm high parapet wall), with other windows being standard height unless specified.

Block 524E: 9th Floor Plan with Unit Layouts

9th floor plan for Block 524E, featuring a mix of unit types and common facilities. Unit types and configurations: - 2-Room Flexi (Type 2): Units 248, 244, 242. Each includes 1 bedroom, living/dining, kitchen, bath/WC, and household shelter. Unit 248 is adjacent to a rental flat. - 3-Room: Unit 250. Features 2 bedrooms (one main), living/dining, kitchen/utility, 2 bath/WC, and household shelter. - 5-Room: Units 240, 238. Each comprises 3 bedrooms (one main), a suggested study area, living/dining, kitchen, service yard, 2 bath/WC, and household shelter. Common facilities include a central lift lobby with two lifts, a staircase, a wash area, and both recyclable and centralised refuse chutes. A linkbridge to Block 522 is present at the 9th storey only. Units at the 12th storey and above in Block 524E are noted to be higher than Block 522. Windows marked W1 are three-quarter height, approximately 550mm high parapet walls.

Block 524E: 10th Floor Plan Layout

10th floor plan for Block 524E. The floor features six residential units and one rental flat. Unit types include: - Three 2-Room Flexi (Type 2) units (242, 244, 248), each with a living/dining area, one bedroom, kitchen, bath/WC, and household shelter. Unit 248 is adjacent to a rental flat. - One 3-Room unit (250) with two bedrooms, living/dining, kitchen/utility, two bath/WCs, and a household shelter. This unit's roof is at the 10th storey only. - Two 5-Room units (238, 240), each featuring a main bedroom, two additional bedrooms, living/dining, kitchen, service yard, two bath/WCs, household shelter, and a suggested study area. Common facilities include a lift lobby with two lifts, stairs, a wash area, and chutes for recyclable and centralised refuse. Units at the 12th storey and above in Block 524E are noted to be higher than Block 522.

General Specifications for 2-Room Flexi Units

General specifications for 2-room Flexi (short lease) units. Foundation: Piled foundations. Structure: Reinforced concrete structural framework with reinforced concrete slabs. Roof: Reinforced concrete roof slab with precast concrete secondary roofing. Walls: Constructed with reinforced concrete, precast panels, drywall partition system, or precast lightweight concrete partitions. Windows: Aluminium framed with tinted glass. Doors: - Entrance: Laminated timber door and metal gate. - Bedroom: Laminated UPVC sliding partition/door (where applicable). - Bathroom/WC: Laminated UPVC folding door. - Household Shelter: Metal door. - Living/Dining: Laminated UPVC folding door (optional). Finishes: - Living/Dining/Bedroom Floor: Vinyl strip flooring with laminated UPVC skirting. - Kitchen/Bathroom/WC/Household Shelter Floor: Glazed porcelain tiles. - Kitchen/Bathroom/WC Walls: Glazed porcelain tiles. - Ceilings/Other Walls: Skim coated or plastered and painted. Fittings: Includes quality locksets, water closet suite, clothes drying rack, grab bars, wash basin with tap/shower mixer. Optional fittings include built-in kitchen cabinets (with induction hob, cooker hood, sink, dish drying rack), built-in wardrobe, window grilles, water heater, and lighting. Services: Gas services, concealed water supply pipes, exposed sanitary stacks at air-con ledge, concealed electrical wiring (lighting, power, water heater, air-conditioning points), television points, and data points. Important Notes: Household Shelter is for civil defence and cannot be altered. Laminated UPVC door frames provided for Bedroom and Bathroom/WC. Unused/unoccupied open spaces are not for purchase or enclosure. Details of services (e.g., gas, water pipes, wiring) are not indicated on plans.

General Building Specifications for HDB Flat Types

General specifications for 2-room Flexi, 3-room, 4-room, and 5-room HDB flats are detailed. Key structural specifications include piled foundations, reinforced concrete structural framework and roof slabs, and walls constructed with reinforced concrete, precast panels, or drywall systems. Windows are aluminium framed with tinted glass. Door types vary by area: laminated timber for entrance, UPVC for bedrooms and bathrooms, metal for household shelters, and aluminium framed glass for service yards. Interior finishes specify vinyl strip flooring for living, dining, and bedrooms, and glazed porcelain tiles for kitchens, utilities, bathrooms, WCs, household shelters, and service yards. Ceilings and other walls are skim coated or plastered and painted. Fittings include quality locksets, water closet suites, clothes drying racks, and bath/shower mixers. Services cover gas, concealed water supply, exposed sanitary stacks, and concealed electrical wiring for lighting, power, water heaters, air-conditioning, television, and data points. Important notes clarify the Household Shelter's civil defence purpose, UPVC door frame provision, and that unused/unoccupied spaces are not for purchase.

HDB BTO Brochure General Disclaimer

General disclaimer for the HDB BTO project brochure, specifically for 'Vanda Breeze @ Yishun'. Key points of the disclaimer include: - HDB owns the copyright to all brochure information. - Content is for general information only, not a contract or factual representation. - Visual representations are artistic impressions. - All project information (dimensions, plans, specifications) is indicative and subject to change by HDB or relevant authorities. - HDB reserves the right to alter amenities, facilities, and design features. - No alterations to flat layouts or specifications will be entertained. - Accuracy of information is not warranted; HDB is not responsible for reliance on it. - Floor areas are scaled strata areas, subject to final survey. - Surrounding land use and proposed facilities are indicative and may lead to higher noise levels from non-residential uses. - HDB reserves the right to use common property (void deck, car park, precinct pavilion, standalone community building) for future amenities (e.g., childcare, elderly facilities, community centers), commercial facilities (shops, eating houses), and mechanical/electrical rooms. - Readers are advised to contact relevant authorities for complete information.

Optional Component Scheme for 2-Room Flexi Flats

This page outlines the HDB Optional Component Scheme (OCS) for 2-room Flexi flats constructed using the Prefabricated Prefinished Volumetric Construction (PPVC) method. This scheme is optional, allowing buyers to select items before their flat selection appointment, with costs added to the flat's selling price. All 2-room Flexi flats include: - Floor finishes in the living/dining room, bedroom, bathroom, household shelter, and kitchen. - Wall tiles in the bathroom and kitchen. - A sliding partition/door for the bedroom and a folding bathroom door. - Sanitary fittings, such as a wash basin with tap mixer, shower set with bath/shower mixer, and a water closet suite. For short-lease 2-room Flexi flats, grab bars are installed to assist elderly buyers. The page includes illustrative images of a shower set, a wash basin, and grab bars. Further details on the OCS package for short-lease 2-room Flexi flats are available on the subsequent page. The document was published in Feb 2022.

Optional Component Scheme for 2-Room Flexi Flats

This brochure page outlines the Optional Component Scheme (OCS) for short-lease 2-room Flexi flats, designed for elderly buyers seeking move-in condition properties. Elderly-Friendly Fittings include: - Built-in kitchen cabinets with induction hob, cooker hood, sink, tap, and dish drying rack. The induction hob offers no open flame, faster cooling, easier cleaning, and a flat surface for stability. - Kitchen cabinets with mobile sections to provide knee space, suitable for wheelchair users. - Built-in bedroom wardrobe with a lower clothes hanging rod for easy reach. - Option for lower counter top height: Default (Option A) has bottom cabinets at 850mm and top at 1600mm; Lowered (Option B) has bottom cabinets at 800mm and top at 1200mm, designed for wheelchair users. - Folding door for the flexible space in 2-room Flexi (Type 2) flats. Other Fittings provided are: - Window grilles for safety and security. - Mirror. - Toilet roll holder. - Lighting. - Water heater. The cost of this OCS package will be added to the selling price of the selected flat.
